Overview:

The SC12B is a self-calibrating capacitive touch sensor that detects whether or not the 12 sense discs have been touched. It can sense capacitive changes through any non-conductive medium such as glass and plastic. This capacitive switch can be used in many electronic products to increase the added value of the product.

Features.

◇ 12 completely independent touch-sensitive buttons.

◇ Maintains automatic correction without external intervention.

◇ Key outputs are fully anti-dithering.

◇Multiple interfaces - I2C serial interface / BCD code output.

◇ Multiple sensitivity adjustment methods - shared sensitivity capacitor/register configuration.

◇ Idle state can save power consumption.

◇ 2.1V ~ 6.0V operating voltage.

◇ Eco-friendly SSOP-24(0.635) package compliant with RoHS directive.

Applications.

◇Replacement of mechanical switches.

◇Home applications (TV, monitor keyboard).

◇ Human-machine interface for toys and interactive games.

◇ Keypad for access control.

◇ Light control switches.

◇ Sealed Keyboard Panel.
