Introduction：

This datasheet provides the ordering information and mechanical device characteristics of the STM32H7B0xB microcontrollers.This document should be read in conjunction with the STM32H7B0xB reference manual (RM0455). The reference manual is available from the STMicroelectronics website www.st.com. For information on the Arm® Cortex®-M7 core, refer to the Cortex®-M7 Technical Reference Manual, available.

Features:

Core

• 32-bit Arm® Cortex®-M7 core with double-precision FPU and L1 cache:16 Kbytes of data and 16 Kbytes of instruction cache allowing to fill one cacheline in a single access from the 128-bit embedded Flash memory; frequency upto 280 MHz, MPU, 599 DMIPS/ 2.14 DMIPS/MHz (Dhrystone 2.1), and DSPinstructions

Memories

• 128 Kbytes of Flash memory plus 1 Kbyte of OTP memory

• ~1.4 Mbytes of RAM: 192 Kbytes of TCM RAM (inc. 64 Kbytes of ITCM RAM +128 Kbytes of DTCM RAM for time critical routines), 1.18 Mbytes of user SRAM,and 4 Kbytes of SRAM in Backup domain

• 2x Octo-SPI memory interfaces with on-the-fly decryption, I/O multiplexing andsupport for serial PSRAM/NOR, Hyper RAM/Flash frame formats, running up to140 MHz in SRD mode and up to 110 MHz in DTR mode

• Flexible external memory controller with up to 32-bit data bus:

– SRAM, PSRAM, NOR Flash memory clocked up to 125 MHz inSynchronous mode

– SDRAM/LPSDR SDRAM

– 8/16-bit NAND Flash memories

• CRC calculation unitSecurity

• ROP, PC-ROP, active tamper, secure firmware upgrade support, Secure accessmodeGeneral-purpose input/outputs

• Up to 138 I/O ports with interrupt capability

– Fast I/Os capable of up to 133 MHz

– Up to 164 5-V-tolerant I/OsLow-power consumption

• Stop: down to 32 µA with full RAM retention

• Standby: 2.8 µA (Backup SRAM OFF, RTC/LSE ON, PDR OFF)

• VBAT: 0.8 µA (RTC and LSE ON)Clock management

• Internal oscillators: 64 MHz HSI, 48 MHz HSI48, 4 MHz CSI, 32 kHz LSI

• External oscillators: 4-50 MHz HSE, 32.768 kHz LSE

• 3× PLLs (1 for the system clock, 2 for kernel clocks) with fractional modeReset and power management

• 2 separate power domains, which can be independently clock gated to maximizepower efficiency:

– CPU domain (CD) for Arm® Cortex® core and its peripherals, which can beindependently switched in Retention mode

– Smart run domain (SRD) for reset and clock control, power managementand some peripherals

• 1.62 to 3.6 V application supply and I/Os

• POR, PDR, PVD and BOR

• Dedicated USB power embedding a 3.3 V internal regulator to supply theinternal PHYs

• Dedicated SDMMC power supply

• High power efficiency SMPS step-down converter regulator to directly supplyVCORE or an external circuitry

• Embedded regulator (LDO) with configurable scalable output to supply thedigital circuitry

• Voltage scaling in Run and Stop mode

• Backup regulator (~0.9 V)

• Low-power modes: Sleep, Stop and Standby

• VBAT battery operating mode with charging capability

• CPU and domain power state monitoring pinsInterconnect matrix

• 3 bus matrices (1 AXI and 2 AHB)

• Bridges (5× AHB2APB, 3× AXI2AHB)5 DMA controllers to unload the CPU

• 1× high-speed general-purpose master direct memory access controller(MDMA)

• 2× dual-port DMAs with FIFO and request router capabilities

• 1× basic DMA with request router capabilities

• 1x basic DMA dedicated to DFSDMUp to 35 communication peripherals

• 4× I2C FM+ interfaces (SMBus/PMBus)

• 5× USART/5x UARTs (ISO7816 interface, LIN, IrDA, modem control) and 1xLPUART

• 6× SPIs, including 4 with muxed full-duplex I2S audio class accuracy via internalaudio PLL or external clock and 1 x SPI/I2S in LP domain (up to 125 MHz)

• 2x SAIs (serial audio interface)

• SPDIFRX interface

• SWPMI single-wire protocol master interface

• MDIO Slave interface

• 2× SD/SDIO/MMC interfaces (up to 133 MHz)

• 2× CAN controllers: 2 with CAN FD, 1 with time-triggered CAN (TT-CAN)

• 1× USB OTG interfaces (1HS/FS)

• HDMI-CEC

• 8- to 14-bit camera interface up to 80 MHz

• 8-/16-bit parallel synchronous data input/output slave interface (PSSI)11 analog peripherals

• 2× ADCs with 16-bit max. resolution (up to 24 channels, up to 3.6 MSPS)

• 1× analog and 1x digital temperature sensors

• 1× 12-bit single-channel DAC (in SRD domain) + 1× 12-bit dual-channel DAC

• 2× ultra-low-power comparators

• 2× operational amplifiers (8 MHz bandwidth)

• 2× digital filters for sigma delta modulator (DFSDM), 1x with 8 channels/8 filtersand 1x in SRD domain with 2 channels/1 filterGraphics

• LCD-TFT controller up to XGA resolution

• Chrom-ART graphical hardware Accelerator (DMA2D) to reduce CPU load

• Hardware JPEG Codec

• Chrom-GRC™ (GFXMMU)Up to 19 timers and 2 watchdogs

• 2× 32-bit timers with up to 4 IC/OC/PWM or pulse counter and quadrature(incremental) encoder input (up to 280 MHz)

• 2× 16-bit advanced motor control timers (up to 280 MHz)

• 10× 16-bit general-purpose timers (up to 280 MHz)

• 3× 16-bit low-power timers (up to 280 MHz)

• 2× watchdogs (independent and window)

• 1× SysTick timer

• RTC with sub-second accuracy and hardware calendarCryptographic acceleration

• AES chaining modes: ECB,CBC,CTR,GCM,CCM for 128, 192 or 256

• HASH (MD5, SHA-1, SHA-2), HMAC

• 2x OTFDEC AES-128 in CTR mode for Octo-SPI memory encryption/decryption

• 1x 32-bit, NIST SP 800-90B compliant, true random generatorDebug mode

• SWD and JTAG interfaces

• 4 KB Embedded Trace Buffer96-bit unique IDAll packages are ECOPACK2 compliant
